Ultrasonic Industrial Equipment "Skifia UZG 200-01"
ULTRASOUND INDUSTRIAL EQUIPMENT "SKIFIA UZG 200-01 was developed using military technologies for effective protection against mice, rats and other rodents in facilities where the use of pesticides and poison chemicals against rodents is strictly prohibited, such as industrial cold rooms, storage warehouses food products, bread reception points, grain processing enterprises and others.
"SKIFIA UZG 200-01" has high reliability
The service life is 10 (ten) years or more if the rules of operation are followed.
Effective coverage area up to 5,000 square meters (depending on the characteristics of the room and the number of ultrasonic emitters). The maximum number of ultrasonic emitters is 170 (one hundred and seventy).
The length of the signal cable is up to 200 meters. Ultrasonic emitters are connected to the signal cable in parallel. Several parallel signal cables are possible. Ultrasonic emitters can be connected to the signal cable using wires of different lengths.
This makes it possible to place ultrasonic emitters inside the cable tracks of elevators, harvesters, telecommunication networks, etc. and thereby prevent damage to the cable insulation by rodents.
The nominal output power in the mode of latitudinal pulsed ultrasonic radiation is 500 W. Power supply - 220 volt network. Power consumption - 600 W per hour at maximum load. So that rodents do not adapt to ultrasonic vibrations, the frequency of pulses is scanned in the range of 19 - 52 kilohertz. The nominal power of ultrasonic emitters is 92+/-3db (1W/10cm). The nominal frequency range of ultrasonic emitters is 2.5 - 55 kilohertz. There is an output power regulator.
In accordance with the order of the State Committee of Ukraine on Technical Regulation and Consumer Policy No. 426 dated 09/22/2010,
"SKIFIA UZG 200-01" is not subject to mandatory certification in Ukraine.
The principle of operation of "SKIFIA UZG 200-01" is based on the emission of ultrasonic vibrations, which change the biorhythms of the nervous system of rodents and prevent rodents from adapting to life in the area of operation of
"SKIFIA UZG 200-01". And the rodents, unable to endure such ultrasonic torture, leave the territory where ultrasonic vibrations are emitted.
"SKIFIA UZG 200-01" consists of the electronics unit and ultrasonic emitters
(ultrasound speakers) that emit ultrasound. Features of "SKIFIA UZG 200-01"
are that all ultrasonic emitters are connected taking into account the phase.
A resonance effect is achieved. Thanks to the resonance effect, the efficiency of
SKIFIA UZG 200-01 is significantly increased.
Director of SCIFIC, Colonel Valery Tymoshenko
PRIVATE COMPANY "SCIFIC"
production of industrial ultrasonic electronics
EDRPOU code 30320236
Website: http://www.alfakatrin.com.ua
tel. mob +380 97 530 04 86
E-mail: Ця електронна адреса захищена від спам-ботів. Вам потрібно увімкнути JavaScript, щоб побачити її., Ця електронна адреса захищена від спам-ботів. Вам потрібно увімкнути JavaScript, щоб побачити її.
09106, Ukraine, Kyiv region, Bila Tserkva.
